50W 60W Road Outdoor LED Street Light Housing IP65 Aluminum Die Casting

50W 60W Road Outdoor LED Street Light Housing IP65 Aluminum Die Casting
50W 60W Road Outdoor LED Street Light Housing IP65 Aluminum Die Casting 50W 60W Road Outdoor LED Street Light Housing IP65 Aluminum Die Casting

Large Image :  50W 60W Road Outdoor LED Street Light Housing IP65 Aluminum Die Casting

Product Details:
Place of Origin: CHINA
Brand Name: DIE-CASTING MAN
Certification: CE ROHS TUV
Model Number: ZHSL-13-50
Payment & Shipping Terms:
Minimum Order Quantity: 1 PCS
Price: USD33.00/PCS
Packaging Details: PE bag+bubble+carton
Delivery Time: 25 days
Supply Ability: 30pcs/per day
Detailed Product Description
Material: ADC 03 Aluminum Input Wattaage: 50W
Color Temperature: 3000/4000/6500K Luminous Flux: 5250-6000 Lm
Color Rendering Index: Ra≥70 LED Lifetime: 50000h
High Light:

street light housing

,

led street light enclosure

50W 60W Road Outdoor LED Street Light Housing IP65 Aluminum Die-Casting NINGBO



Material: ADC 3 Aluminum Wattage: 50W 60W
IP: 65 CRI: ≥70
Color Temperature: 3000/40000/6500K Input Voltage: AC90 - 265V
Frequency Range: 50 - 60Hz Working Ambient Temperature: -40℃ - 50℃
Working Ambient Humidity: 20% - 90%RH LED Lifetime: 5000h



50W 60W Road Outdoor LED Street Light Housing IP65 Aluminum Die-Casting NINGBO



Part Number: ZHSL-13-50
Production Lead Time: 7-30 Days
MOQ: 1 PCS
Shipping: EXW / FOB NINGBO
Finish Color: Double gray;Sandy black;





































Specifications



Model Number ZHSL-13-50
Electrical Specifications

Frequency Range

50/60Hz
Input Wattage 50W 60W
Input  Voltage AC90-305V
Operating Humidity 20%~90%RH
Working Temperature -40 ~ 50°C
Power Fact(PF) >0.95
Driver Efficiency > 0.9
Photometric Specifications LED Luminous Flux 5250~6000 lm
Power Factor PF≥0.92
Led Luminous Efficiency >100LM/W
CRI Ra ≥ 70
Color Temperature 3000/4000/6500k
Mechanical Specifications IP Rating IP66
Warranty 3Years
Heat Radiator die-casting body as heat sink
Lens Patented anti-glare optic lense
Fixture Dimension 641X241X114 MM
Fixture Weight 3.9 KG



Packing Information

Packing Type 1 unit /ctn
Packing Dimension 71X30X15 mm
Packing Weight 4.7 KG

50W 60W Road Outdoor LED Street Light Housing IP65 Aluminum Die Casting 0

50W 60W Road Outdoor LED Street Light Housing IP65 Aluminum Die Casting 1



LED Engine Module

· LED life time of 50,000hours

· High power integrated packaging LED chips, 120° beam spread available

· Minimum CRI of 70, custom CRI available

· Operating temp: -40º C to +50º C

· No toxic chemicals / ROHS compliant

· Low Tj for long life, low lumen depreciation

· CE certified, meets ROHS standards

· Eligible for Rebates, Design Lights Consortium® Qualified

· 50-80% energy savings

· Manufactured in the China

· Standard distribution is Type V, others distributions available

Electrical

· Standard AC input of 90-305V,up to 480v available

· EMI filter: 47CFR, part 2, part 15

· Power factor: >0.9

· Total harmonic distortion: <20%

· Surge protection: IEC/EN 61000-4-5 EMC test standard

· Licensed electrician required for installation

Housing

· Rugged, fully sealed, die-cast aluminum housing

· UV-resistant, multi-layer, architectural color, powder coat finish

· High impact, heat resistant, tempered lens

50W 60W Road Outdoor LED Street Light Housing IP65 Aluminum Die Casting 2
