Product Details:
Payment & Shipping Terms:
|
| Item: | ZHHB-05-150 | Material: | Die-Casing Aluminium |
|---|---|---|---|
| Wattage: | 150W | LED Lifetime: | 5000h |
| Protection Grade: | IP66 | Pole Size: | 60mm |
| Colour: | Black And Grey | Product Size: | 342*342*119mm |
| High Light: | led high bay light fixtures,led high bay lamp |
||
ZHHB-05 Family Product Spencification
| Product Code | ZHHB-05-100 | ZHHB-05-150 | ZHHB-05-200 |
| Input Wattage | 100W | 150W | 200W |
| Color Temperature | 3000-6500K | 3000-6500K | 3000-6500K |
| Luminous Flux | 12000-14000lm | 18000-19600lm | 24000-28000lm |
| Input Voltage | AC90-305V | AC90-305V | AC90-305V |
| Frequency Range | 50/60Hz | 50/60Hz | 50/60Hz |
| Power Factor | PF≥0.95 | PF≥0.95 | PF≥0.95 |
| Color rendering index | Ra≥70 | Ra≥70 | Ra≥70 |
| Temperature of working condition | -40-50℃ | -40-50℃ | -40-50℃ |
| Humidity of working condition | 20%-90%RH | 20%-90%RH | 20%-90%RH |
| LED Lifetime | 50000h | 50000h | 50000h |
| Protection Grade | IP66 | IP66 | IP66 |
| Light Angle | 60°/90°/120° | 60°/90°/120° | 60°/90°/120° |
| Net Weight | 3.5kgs | 4.8kgs | 6.5kgs |
| Gross Weight | 4.5kgs | 5.8kgs | 7.5kgs |
| Packing Size(mm) | 295*295*165 | 355*355*165 | 415*415*175 |
| Product Size(mm) | 282*282*115 | 342*342*119 | 403*403*128 |
Photometric Data
Line Drawing
Product Description
*This series is a high-performance street lighting available in three size
*The luminaire is manufactured from high pressure die-casting aluminum
*It shall have a led efficiency up to 120lm/w and will be capable of producing up to 18000luminair lumens at 4000K finished in grey or black as standard.
