Product Details:
Payment & Shipping Terms:
|
| Model: | FAP830 | Input Voltage: | AC180-240V |
|---|---|---|---|
| Working Time (hours):: | 50000h | Product Color: | Black Grey Silver |
| Cri (ra>): | 70 | Ip Rating: | IP65 |
| High Light: | Outdoor LED Flood Light 10w,Square Outdoor Led Flood Light 50w,Square Led Stadium Flood Light |
||
Features:
*Power:10w-300w
*Power Factor:>95%
*Color Temperature:3000k-6500k
*Working Voltage:AC180-240V
*CRI:>80
*Flux:1000lm-30000lm
*Waterproof:IP66
*Lamp Body Material:Aluminum
*Lamp Luminous Efficiency(lm/w):100
*IP65 waterproof/dust proof/explosion proof/IK08
*Pure Aluminum shape good at heat dissipation
*Angle Bracket,easy to install by drill.Easy replacement and installation
*SMD 2835 Ra>70/SDCM<7
*50,000 times switching cycle before failure.Total harmonic distortion(THD)<20%
*Temperature Operating -20~+45ºC.Storage -40~+60ºC
Application:
Large retailers / School / Billboard / Building/Airports / Stadium / Train stations / Bus stations/Factory Warehouses / Parking lots/ Exhibition centers/ Gas stations / Toll stations etc.
Product Specification:
| Model | Power | Light Source | LED QTY | CCT(K) | LM/W | CRI |
| FAP81-10W | 10 | 2835 | 13 | 6500k | 85 | >70 |
| FAP82-20W | 20 | 2835 | 26 | 6500k | 85 | >70 |
| FAP83-30W | 30 | 2835 | 39 | 6500k | 90 | >70 |
| FAP85-50W | 50 | 2835 | 78 | 6500k | 90 | >70 |
| FAP810-100W | 100 | 2835 | 143 | 6500k | 90 | >70 |
| FAP815-150W | 150 | 2835 | 195 | 6500k | 90 | >70 |
| FAP820-200W | 200 | 2835 | 286 | 6500k | 90 | >70 |
| FAP830-300W | 300 | 2835 | 390 | 6500k | 90 | >70 |
| FAP840-400W | 400 | 2835 | 507 | 6500k | 90 | >70 |
Product Dimension:
| Model NO. | Size L(mm) | Size W(mm) | Size H(mm) |
| FAP81 | 104 | 83.4 | 25.7 |
| FAP81-PIR | 104 | 160 | 45 |
| FAP82 | 121 | 95.3 | 26.4 |
| FAP82-PIR | 121 | 165 | 45 |
| FAP83 | 161 | 123.2 | 29.6 |
| FAP83-PIR | 161 | 197 | 45 |
| FAP85 | 207 | 161 | 31.5 |
| FAP85-PIR | 207 | 228 | 45 |
| FAP810 | 269 | 209 | 34 |
| FAP815 | 330 | 250 | 34 |
| FAP820 | 388 | 288 | 36 |
| FAP830 | 445 | 334 | 45.5 |
| FAP840 | 490 | 410 | 48 |
Lighting Instribution:
