Economic Style TUV CE RoHs ENEC Approved LED Street Light Fixtures 40W to 180W Road & Industrial Area 3 Sizes
Item NO.: ZHSL-05-60
ZHSL-05-40
ZHSL-05-60
ZHSL-05-120
Technical Specifications:
| Item NO. |
ZHSL-05-40 |
ZHSL-05-60 |
ZHSL-05-120 |
| LED Quantity |
18pcs |
54pcs |
80pcs |
| Rated Power |
30W |
80W |
120W |
| Color Temperature |
2700-6500K |
2700-6500K |
2700-6500K |
| Initial Luminous Flux |
3000LM |
8000LM |
12000LM |
| Input Voltage |
AC100-240V |
AC100-240V |
AC100-240V |
| Frequency Range |
50-60Hz |
50-60Hz |
50-60Hz |
| Power Factor |
PF>0.95 |
PF>0.95 |
PF>0.95 |
| Color Rendering Index |
Ra>70 |
Ra>70 |
Ra>70 |
| Temperature Working Condition |
-40℃ - 50℃ |
-40℃ - 50℃ |
-40℃ - 50℃ |
| Humidity of Working Condition |
20-90% |
20-90% |
20-90% |
| LED Lifetime |
50000h |
50000h |
50000h |
| Protection Grade |
IP65 |
IP65 |
IP65 |
| Installation Pipe Diameter |
60mm |
60mm |
60mm |
| Installation Height |
6-8m |
6-8m |
6-8m |
| Net Weight |
2.9kgs |
5.5 kgs |
9.5 kgs |
| Gross Weight |
3.3kgs |
6 kgs |
10.5kgs |
| Packing Size |
52*28*14 cm |
71*35*16 cm |
91.5 x42x19 cm |
Production Description:
- SL-05 series luminaire is the ideal solution that fulfills requirements of functional street lighting and residential areas, which working with outstanding heat dissipation and compacting system. Equipped with high-quality electrical components, long lifespan is assured. Dis-connector device, enable easy, safe and minimal cost for maintenance. Efficient system also reduce energy consumption and creat a more attractive urban living environment and visual comforts for public and residential areas.
- With patented housing design and range of optics, SL-03 series luminaires is also a perfect choice for project oriented usage.
Features:
- European standard high-pressure aluminium housing material ADC-3
-Patented Ribbon-Free housing technology
- Excellent thermal management
- Outstanding self-cleaning capability
- Patented optics for increased application efficiency
- Post-top or side-entry mounted +10° or -10° title
- Toughed glass with 4mm thickness, IK08 Impact Resistance; IK09 with 5mm glass optional
LED Engine Module
LED life time of 100,000 hours at 25℃ ambient temperature
Lumiaire efficiency: 110-130lm/w
CCT: 4000k (3000K/ 5000K/ 5700K upon request)
CRI: >70; >80 (upon request)
Operating temperature range: -30 to 45 ℃
Electrical
MeanWell / Inventronics optional (other brand of driver upon request)
Class I or Class II
Input Voltage: 90-305VAC/50-60Hz, 170-305VAC/ 50-60Hz
10KV/20KV SPD
Power automatically switch off when opening
Dimming:
Dali
1-10V
PWM
AstroDIM for autonomous dimming with five independent levels
Smart control management system
Options:
Photocell
Surge protection device (up to 20KV)
0.5m External cable(Other length upon request)
Smart control device
Motion detection
Standards & Certifications:
CE, ROHS, ENEC pending, GS pending, IEC pending, LM79 pending, TM21 pending
