Product Details:
Payment & Shipping Terms:
|
| Material: | ADC12 Aluminum | Wattage: | 80W |
|---|---|---|---|
| IP: | 66 | CRI: | >70 |
| LED Color: | WW/NW/CW | Input Voltage: | AC85 - 265V |
| Frequency Range: | 50 - 60Hz | Working Ambient Temperature: | -30℃ - 50℃ |
| Working Ambient Humidity: | 10% - 90% | IK: | 08 |
| High Light: | Ik08 Urban LED Lighting,ip66 Urban LED Lighting,80watt Urban LED Lighting |
||
Product Description:
| Product Code | ZHSL-19-30 | ZHSL-19-50 | ZHSL-19-80 | ZHSL-19-150 | |
| Input Wattage | 30W | 50W | 80 W | 150W | |
| Color Temperature | 3000-6500K | 3000/4000/6500 | 3000/4000/6500 | 3000/4000/6500 | |
| Luminous Flux | 3300-3750 lm | 5500-6250 lm | 9200-10400 lm | 16500-19500 lm | |
| Input Voltage | AC90-305V | AC 90-305 V | AC 90-305 V | AC 90-305 V | |
| Frequency Range | 50/60Hz | 50/60 Hz | 50/60 Hz | 50/60 Hz | |
| Power Factor | PF≥0.95 | PF≥0.95 | PF≥0.95 | PF≥0.95 | |
| color rendering index | Ra≥70 | Ra≥70 | Ra≥70 | Ra≥70 | |
| Temperature of Working Condition | -40-50℃ | -40--50℃ | -40--50℃ | -40--50℃ | |
| Humidity of Working Condition | 20%-90%RH | 20%-90%RH | 20%-90%RH | 20%-90%RH | |
| LED Lifetime | 50000h | 50000 h | 50000 h | 50000 h | |
| Protectin Grade | IP66 | IP 66 | IP 66 | IP 66 | |
| Installation Pipe Diameter | φ60mm | φ60 mm | φ60 mm | φ70 mm | |
| Installation Height | 4-6m | 4-6 m | 5-8 m | 10-12 m | |
| Net Weight | 3 kgs | 3.5 kgs | 5 kgs | 6.4 kgs | |
| Gross Weight | 3.5 kgs | 4 kgs | 6 kgs | 7.4 kgs | |
| Packing Size | 51*23.6*15 cm | 63*28*15.5 cm | 67*31*16 cm | 82.5834*16 cm | |
Applications:
Motorways,Major roads,minor roads,roundabouts,crossing and industrial areas.
Our advantage
1. Good supply chain management . We have build a good relationship with many international brand
( Bridgelux , San’an , , Osram , Meanwell , , etc). That will help us get high quality led chip, led driver, lens on time.
2. Professional staffs. We have more than 100 staffs.The workers are skilled.They know the products very well
from a screw to the whole product. They know the key point during production process and how to deal with if there is a problem.
3. Advanced equipments. We have many advanced equipments. That will make sure that our products are produced in high standard
and strict process.
A: what kind of material will you use?
B: normally we use YA001.and international standard aluminium ADC12.
A: How many hours will these machines work a day?
B: This workshop working 24hours a day.
A: How is the monthly capacity?
B: for housing, 140,000pcs per month. For finished Luminaire, 10,000pcs per month.
A: Is there a personnel-training program in place?
B :yes.we will train our employees regularly.
A: How do you control quality of die casting part?
B: we will inspect it according to the 2D drawing.the tolerance is plus or minus 5mm.
A: how about your defective rate?
B: About three over one thousand in normal operations.
A: can you offer OEM and ODM service?
B: yes.we used to help our clients to develop hundreds kind of toolings already.
A:Can you produce according to the samples or drawings?
B: Yes, we can produce by your samples or technical drawings.
We can build the molds and fixtures.
A :If i want to buy your models.can you help me to show our logo on your housing?
B: yes.we have two options.we can made a insert to show your logo as 3D effect or print your logo on housing.
