Product Details:
Payment & Shipping Terms:
|
| Power: | 50W | Efficiency: | 130lm/w |
|---|---|---|---|
| Lumen: | 6500lm | LED: | Lumileds |
| Housing Color: | Gray | Pole Size: | 50mm/60mm |
| High Light: | Outdoor LED Street Lights 6500K,50w Outdoor LED Street Lights,Major Road Outdoor LED Street Lights |
||
Product Specification
| Product Datasheet | |||||||
| Item No. | SL105-30W-S | SL105-50W-S | SL105-60W-S | SL105-80W-M | SL105-100W-M | SL105-120W-L | SL105-150W-L |
| Power | 30W | 50W | 60W | 80W | 100W | 120W | 150W |
| Lumen Efficiency | 130lm/w | 130lm/w | 130lm/w | 130lm/w | 130lm/w | 130lm/w | 130lm/w |
| Lumen | 3900lm | 6500lm | 7800lm | 10400lm | 13000lm | 15600lm | 19500lm |
| Product Size (mm) | 456x122x13 | 456x122*13 | 456x122*13 | 536x166x13 | 536x166*13 | 618x461x13 | 618x461*13 |
| Electrical Data | |||||||
| Working Voltage | AC100-265V 丨 50/60Hz | ||||||
| LED: | Lumileds / Epistar / SANAN | ||||||
| CCT | 3000K, 4000K, 5000K ,6000K | ||||||
| CRI | Ra>70 (standard)/ Ra>80 | ||||||
| Driver | local | ||||||
| THD | <15% | ||||||
| Power Factor(PF) | PF>0.9 | ||||||
| IP Rating | IP66 | ||||||
| IK Rating | 1K09 | ||||||
| Holder | 50mm/B60mm (standard) | ||||||
| Body Material | Hign pressure die-cast aluminum | ||||||
| Housing Calor | Dark Grey/Black/Light Grey (availabel on request) | ||||||
| Cover Material | UV-resistant Polycarbonate | ||||||
| Working Environment | -20℃ ~+50℃ , 10%~90%RH | ||||||
| Lifespan L70 at 25℃ | > 50,000hrs | ||||||
| Mounting Type | Side entry or Vertical pole mounted ±15° | ||||||
| Dimmable | 1-10V Dimming /Timer Dimming | ||||||
| Protecdion Class | Class I (standard) / Class Ⅱ | ||||||
| Standards | CE, RoHS, ENEC, CB, LM79. LM80, TM-21, IP66, IK09 | ||||||
| Available on request | NEMA socket (3/5/7pins), ZHAGA socket. Short cap, Photocell., Motion sensor, NTC. OLC, DALI Dimming | ||||||
| Reasonable tolerance | Watt: ±10%,CCT:±500K, Lumen efficiency: ±5% | ||||||
Equipment
Exihibition
Ningbo Die-casting Man Techonology Co.,LTD. was founded in 1996 and is located in Ninghai Mould Centre,
close to Ningbo port and Shanghai port.
Factory covers an area of 15,000 square meters and has 100 employees. We are a professional factory engaged in research,
design, production, sale and service of street light and die-casting injection OEM and ODM products.
Our products sale mainly to Europe, Asia and domestic /dəˈmestɪk/ market.
We have die-casting injection, CNC machining, metal punching, powder painting, assembling and testing in house.
Our R&D department will develop 5-10 new products yearly. Besides design and production process,
we work under ISO9001 quality control system to make sure our quality is consistent and well controlled.
Our main products are street light and die-casting OEM injection products.
Current we have 24 series street light and various customer OEM products.
Our street lights are available from 20W to 240W mainly. Every series we have small, medium and large size and some have mini version.
If you do not like current version, we can also design the one to meet your market. We are a company never stand still on products and service.
