Product Details:
Payment & Shipping Terms:
|
| Material: | Die-casting Aluminium | Power: | 100W |
|---|---|---|---|
| Protection Grade: | IK08 And IP65 | LED: | 3030 Or 5050 |
| Application: | Commercial Lighting | Power Factor: | 0.9 |
| High Light: | waterproof IP65 Flood Street Light,100W LED Flood Street Light,Stadium Floodlight For Gas Station |
||
Product Description:
1.TECHNICAL PARAMETERS:
LED Power Consumption: 10W-400W
Operating Voltage: AC200-260V 50/60HZ
Power Factor: >0.9;
LED Luminous Efficiency:90 lm/W
Color rendering index:Ra≥80;
Material: Die-casting aluminum body;
IP Rating: IP65;
Warranty: 3 years;
Finishes: White/Black/Gray
| Item | Actual Wattage | IP Grade | die casting aliumium Weight(G) | product weight G | Dimension(cm) | Cable | Rendering Index |
| SLFAP81 10W | SMD 10W | IP65 | 71 | 180 | 104*83.4*25.7 | 15CM H05RN-F3G1.0mm2 rubber cable | 70 |
| SLFAP82 20W | SMD 20W | IP65 | 91 | 250 | 121*95.3*26.1 | 15CM H05RN-F3G1.0mm2 rubber cable | 70 |
| SLFAP83 30W | SMD 30W | IP65 | 142 | 406 | 161*123.2*29.6 | 15CM H05RN-F3G1.0mm2 rubber cable | 70 |
| SLFAP85 50W | SMD 50W | IP65 | 267 | 670 | 207*161*31.5 | 15CM H05RN-F3G1.0mm2 rubber cable | 70 |
| SLFAP810 100W | SMD 100W | IP65 | 502 | 1390 | 269*209*34 | 15CM H05RN-F3G1.0mm2 rubber cable | 70 |
| SLFAP815 150W | SMD 150W | IP65 | 963 | 2100 | 330*250*34 | 20CM H05RN-F3G1.0mm2 rubber cable | 70 |
| SLFAP820 200W | SMD 200W | IP65 | 1408 | 3000 | 388*288*36 | 20CM H05RN-F3G1.0mm2 rubber cable | 70 |
| SLFAP830 300W | SMD 300W | IP65 | 2313 | 4650 | 445*334*45.5 | 20CM H05RN-F3G1.0mm2 rubber cable | 70 |
| SLFAP840 400W | SMD 400W | IP65 | 2935 | 6480 | 490*410*48 | 20CM H05RN-F3G1.0mm2 rubber cable | 70 |
2. FEATURES:
IP65 waterproof/dust proof/explosion proof/IK08
Pure Aluminum shape good at heat dissipation
Angle Bracket,easy to install by drill
Easy replacement and installation
SMD 3030 Ra>70/SDCM<7
50,000 times switching cycle before failure
Total harmonic distortion(THD)<20%
3.Product Dimension
Equipment
Company Profile:
Die Casting Man set up a new joint venture company named Ningbo Die Casting Man Energy Co., Ltd.
We are moving into our new big factory on Dajiahe Industrial Zone, Ninghai Town.
Office still available in our old factory No.225 Tanshu Road Ninghai.
Dajiahe Factory covers an area of over 90000 square meter which is 100 kilometer from Ningbo Sea port
and 70 kilometer from Ningbo Airport.
It will a complete lighting industrial zone specialized in design, mold making, production, marketing and service.
New company focused on supply illumination and electrical products not only street light and die casting OEM,
but also floodlight, highbay, tunnel light and plant light
We are moving all our facilities since beginning of this year and here comes some photos of our factory now.
Till now die casting ejection, CNC machinning, punching and assembling are already on line now.
New painting system will be put into use during this July.
New painting system have auto clearning and pretreatment system which will improve our pretreatment level.
We could make painting level from C3, C4 upto C5 now. This will be very helpful on our finish treatment.
Contact Person: Ms. Jenny
Tel: 0086 13777291746
Fax: 86-574-65579302
