Product Details:
Payment & Shipping Terms:
|
| Model: | FAP820 | Power: | 200W |
|---|---|---|---|
| Led Chip: | 2835 | Working Time (hours):: | 50000h |
| Name: | Led Flood Light | Product Color: | Black |
| High Light: | IP65 Waterproof Led Flood Light,SMD2835 Aluminum Led Flood Light,Outdoor Waterproof Led Stadium Lights |
||
at the places where need a large amount light such as parking lots, driveways, outdoor courts (basketball, tennis, volleyball, etc.).
With the dusk to dawn function.
| Item | Actual Wattage | IP Grade | die casting aliumium Weight(G) | product weight G | Dimension(cm) | Cable | Rendering Index |
| SLFAP81 10W | SMD 10W | IP65 | 71 | 180 | 104*83.4*25.7 | 15CM H05RN-F3G1.0mm2 rubber cable | 70 |
| SLFAP82 20W | SMD 20W | IP65 | 91 | 250 | 121*95.3*26.1 | 15CM H05RN-F3G1.0mm2 rubber cable | 70 |
| SLFAP83 30W | SMD 30W | IP65 | 142 | 406 | 161*123.2*29.6 | 15CM H05RN-F3G1.0mm2 rubber cable | 70 |
| SLFAP85 50W | SMD 50W | IP65 | 267 | 670 | 207*161*31.5 | 15CM H05RN-F3G1.0mm2 rubber cable | 70 |
| SLFAP810 100W | SMD 100W | IP65 | 502 | 1390 | 269*209*34 | 15CM H05RN-F3G1.0mm2 rubber cable | 70 |
| SLFAP815 150W | SMD 150W | IP65 | 963 | 2100 | 330*250*34 | 20CM H05RN-F3G1.0mm2 rubber cable | 70 |
| SLFAP820 200W | SMD 200W | IP65 | 1408 | 3000 | 388*288*36 | 20CM H05RN-F3G1.0mm2 rubber cable | 70 |
| SLFAP830 300W | SMD 300W | IP65 | 2313 | 4650 | 445*334*45.5 | 20CM H05RN-F3G1.0mm2 rubber cable | 70 |
| SLFAP840 400W | SMD 400W | IP65 | 2935 | 6480 | 490*410*48 | 20CM H05RN-F3G1.0mm2 rubber cable | 70 |
Features:
IP65 waterproof/dust proof/explosion proof/IK08
Pure Aluminum shape good at heat dissipation
Angle Bracket,easy to install by drill
Easy replacement and installation
SMD 3030 Ra>70/SDCM<7
50,000 times switching cycle before failure
Total harmonic distortion(THD)<20%
Application:
COMMERCIAL LIGHTING
Large retailers / School / Billboard / Building .etc
PUBLIC LIGHTING
Airports / Stadium / Train stations / Bus stations
INDUSTRIAL LIGHTING
Factory Warehouses / Parking lots/ Exhibition centers/ Gas stations / Toll stations etc.
IP66 CE ROHS
Temperature Characteristics T-ambient 25ºC
Temperature Operating -20~+45ºC
Storage -40~+60ºC
Electrical Characteristics
Input Voltage:AC180-240V / AC127V / AC100-240V
50/60Hz PF:>0.9
Power Efficiency:>=0.90
Product Dimension
| Model NO. | Size L(mm) | Size W(mm) | Size H(mm) |
| FAP81 | 104 | 83.4 | 25.7 |
| FAP81-PIR | 104 | 160 | 45 |
| FAP82 | 121 | 95.3 | 26.4 |
| FAP82-PIR | 121 | 165 | 45 |
| FAP83 | 161 | 123.2 | 29.6 |
| FAP83-PIR | 161 | 197 | 45 |
| FAP85 | 207 | 161 | 31.5 |
| FAP85-PIR | 207 | 228 | 45 |
| FAP810 | 269 | 209 | 34 |
| FAP815 | 330 | 250 | 34 |
| FAP820 | 388 | 288 | 36 |
| FAP830 | 445 | 334 | 45.5 |
| FAP840 | 490 | 410 | 48 |
Mounting hole size
| FAP81 | 50 | 14.5 | 6.5 |
| FAP82 | 57 | 14.5 | 6.5 |
| FAP83 | 57 | 14.5 | 6.5 |
| FAP85 | 129.5 | 14.5 | 6.5 |
| FAP810 | 140 | 20 | 8.3 |
| FAP815 | 140 | 20 | 8.3 |
| FAP820 | 240 | 20 | 8.3 |
| FAP830 | 240 | 20 | 8.3 |
| FAP840 | 240 | 22 | 11 |
| Model | Power | Light Source | LED QTY | CCT(K) | LM/W | CRI |
| FAP81-10W | 10 | 2835 | 13 | 6500k | 85 | >70 |
| FAP82-20W | 20 | 2835 | 26 | 6500k | 85 | >70 |
| FAP83-30W | 30 | 2835 | 39 | 6500k | 90 | >70 |
| FAP85-50W | 50 | 2835 | 78 | 6500k | 90 | >70 |
| FAP810-100W | 100 | 2835 | 143 | 6500k | 90 | >70 |
| FAP815-150W | 150 | 2835 | 195 | 6500k | 90 | >70 |
| FAP820-200W | 200 | 2835 | 286 | 6500k | 90 | >70 |
| FAP830-300W | 300 | 2835 | 390 | 6500k | 90 | >70 |
| FAP840-400W | 400 | 2835 | 507 | 6500k | 90 | >70 |
Floodlight Requirements - 5 Years Warranty Product
