Product Details:
Payment & Shipping Terms:
|
| Wattage: | 50w | Material: | Aluminum Die Casting Body |
|---|---|---|---|
| Input Voltage: | AC85 - 265V | Frequency Range: | 50 - 60Hz |
| Color: | Gray/Black/White | LED: | COB |
| IP Rating: | IP66 | Installation Pipe Dia.: | φ50mm |
| High Light: | 100000 Lumen Garden Light,Outdoor Led Garden Lights 50w,Die Casting Aluminum Housing Street Light |
||
Top quality Outdoor Led garden lights 50W Energy Saving High Brightness
Product Specification:
| Product Code | YAGD-01-50 |
| Input Wattage | 50W |
| Color Temperature | 3000-6500K |
| Luminous Flux | 5500-6500 lm |
| Input Voltage | AC90-305V |
| Frequency Range | 50/60Hz |
| Power Factor | PF≥0.95 |
| color rendering index | Ra≥70 |
| Temperature of Working Condition | -40-50ºC |
| Humidity of Working Condition | 20%-90%RH |
| LED Lifetime | 50000h |
| Protection Grade | IP66 |
| Installation Pipe Diameter | Ø50mm |
| Installation Height | 6-8m |
| Net Weight | 4.4kg |
| Gross Weight | 5.2kg |
| Packing Size(mm) | 390×390×150 |
Streetlight Requirements - 5 years Warranty Product
| S.No | Requirement | Requirement | Test Standard |
| Physical requirements | |||
| 1 | Housing type | Heavy-duty rugged pressure die-cast aluminium alloy | ISO 3522 |
| 2 | Cover | Tempered Glass | |
| 3 | Gasket | Silicon Rubber gasket | |
| 4 | Housing wattage range | 30W 40W 50W 60W 80W 100W 150W 200W 220W 240W | |
| 5 | Socket Options | NEMA socket, Photocell, Smart controller, Shorting Cap | |
| 6 | Stainless-steel components | Minimum 316L Grade 316L | |
| 7 | IP Protection | IP66 | IEC 60529 |
| 8 | IK Protection | IK08 | IEC 62262 |
| 9 | Tool free opening | Tool-free access to gear compartment | |
| 10 | Corrosion tests in artificial atmospheres - Salt spray tests | EN/ISO 9227 - Corrosion tests in artificial atmospheres - Salt spray tests for 1000 hours | EN/ISO 9227 |
| 11 | Vibration test | ANSI C136.31 - Roadway and Area Lighting Equipment - Luminaire Vibration | ANSI C136.31 |
| LED and Optics | |||
| 1 | LED Make | Osram/CREE | |
| 2 | LED Type | >2W High power LED with ceramic base (3V - Single chip die) >2w | |
| 3 | LED driving current | <750mA | |
| 4 | LED life | >100,000 hours @L95 | LM80 and TM21 |
| 5 | Optics Material | UV PC | |
| 6 | Lighting distributions | Type I, II, III, IV | |
| Thermal Requirements | |||
| 1 | Product ambient temperature range | -40°C to 55°C | |
| 2 | Product Storage temperature range | up to 85°C | |
| 3 | LED Case temperature (Tc) | <75°C @50°C ambient temperature | UL1598 |
| 4 | Driver Case temperature range | <85°C @50°C ambient temperature | UL1598 |
| Performance | |||
| 1 | Input Voltage Range | 110V 120V 220V 270 305VAC - 50/60Hz | IEC 60598-2-3 |
| 2 | Power Factor | >0.90 | IEC 60598-2-3 |
| 3 | THD | <20% | IEC 60598-2-3 |
| 4 | Surge Protection | 10KV | |
| 5 | Dimming | 1-10V or 1-10V+DALI | |
| 6 | Appliance class | Class I or Class II | IEC 60598-2-3 |
| 7 | CCT | 3000K/4000K/5700K | ANSI C78.377A |
| 8 | CRI | >70Ra | ANSI C78.377A |
| 9 | MacAdam | <3 Step Binning | ANSI C78.377A |
| 10 | Product life | >100,000 hours @L80 | TM28 |
| 11 | Lumen efficacy As per LM-79 | ≥ 160lm/W (25°C ambient temperature) | LM-79 |
| 12 | Lumen efficacy As per LM-82 | Not more than 5% difference form LM79 result | LM-82 |
| 13 | LED module connector and wire joint connectors | UL approved | IEC 60598-2-3 |
| 14 | Electrical wires between Driver and LED modules and NEMA socket and driver | Must be UL approved | IEC 60598-2-3 |
Feature
.Die casting aluminum body with anti-corrosion treatment.
.Highly polished aluminum reflector.
.Toughened glass with good light transmition rate.
.IP66 Rated for external use
.Equipped with COB LED chip, generate high luminous flux
.LED emiiter brand can be varied according to requirement.
.High efficient and power factor LED power supply.
.Longlife span over 50000 Hours.
.Obtain a 50-70% Energy Saving compared with Halogen Lamps.
