Product Details:
Payment & Shipping Terms:
|
Manufacturer: | Die Casting Man | Material: | Aluminum |
---|---|---|---|
Input Voltage: | AC85 - 265V | Frequency Range: | 50 - 60Hz |
LED Color: | WW/NW/CW | Beam Angle: | 120° |
High Light: | 40W Urban Area Road Lighting Fixtures,Aluminum Road Lighting Fixtures,AC85V Outdoor Street Light Fixtures |
Exterior Industrial Led Flood Lights 20w Led Floodlight High Efficient
Product Code | ZHSL-05-60 | |
Input Wattage | 100W | |
Color Temperature | 3000-6500K | |
Luminous Flux | 10500-12500 lm | |
Input Voltage | AC90-305V | |
Frequency Range | 50/60Hz | |
Power Factor | PF≥0.95 | |
color rendering index | Ra≥70 | |
Temperature of Working Condition | -40--50℃ | |
Humidity of Working Condition | 20%-90%RH | |
LED Lifetime | 50000h | |
Protectin Grade | IP66 | |
Installation Pipe Diameter | φ50-60mm | |
Installation Height | 4-8m | |
Net Weight | 6.5 KG | |
Gross Weight | 7.0 KG | |
Packing Size | 700*350*160mm |
Description:
20W Outdoor Led Floodlight with Bridgrlux LED Chips as 9600lumens output,high quality die-casting aluminum body,IP65,3Years warranty.
1. High light intensity , simple designs and ideally suited.
2. High quality Die casting aluminum boday with anti-corrosiontreatment and with electrostatic plastic coating.
3. LED Floodlight housing can make 20W-30W.
4. Highly polished aluminum reflector.
5. Adjustable single bracket could make the light for 120 degree around.
6. High Efficient and power factor led power supply .
7. Obtain a 50-70% energy saving compared with halogen lamps.
8. Replace traditional SON and Metal Halide which consume 400W.
Applications:
Lighting Walls,Advertisement Boards,Gardens,Hotels,Car Parks,Area with CCTV.
Specifications
Model Number |
YASL-05-60 | |
Electrical Specifications |
LED QTY |
120pcs |
TotaLPower consumption |
90W |
|
Operation Voltage |
85-265VAC |
|
Operating Humidity |
10%~90% |
|
Working Temperature |
-30 ~ 50°C |
|
Power Fact(PF) |
>0.9 |
|
Driver Efficiency |
> 0.9 |
|
Photometric Specifications |
LED Luminous Flux |
1700 lm - Initial |
|
2000 lm - Maintain |
|
Led Luminous Efficiency |
>70LM/W |
|
CRI |
Ra ≥ 70 |
|
LED Color |
3000k-6500k |
|
Beam Angle |
120 degree |
|
Mechanical Specifications |
IP Rating |
IP66 |
Warranty |
3Years |
|
Heat Radiator |
die-casting body as heat sink |
|
Lens |
Patented anti-glare optic lense |
|
Fixture Dimension |
115.06*141.9*51.14MM |
|
Fixture Weight |
|
|
Packing Information |
Packing Type |
2pcs /ctn |
Packing Dimension |
69*56*44CM |
|
Packing Weight |
7KGS |
