Buildings Stadium High Bay Flood Light 600W Outdoor Tennis Court Light

Buildings Stadium High Bay Flood Light 600W Outdoor Tennis Court Light
Buildings Stadium High Bay Flood Light 600W Outdoor Tennis Court Light Buildings Stadium High Bay Flood Light 600W Outdoor Tennis Court Light Buildings Stadium High Bay Flood Light 600W Outdoor Tennis Court Light

Large Image :  Buildings Stadium High Bay Flood Light 600W Outdoor Tennis Court Light

Product Details:
Place of Origin: CHINA
Brand Name: Die-casting man
Certification: CE, RoHs
Model Number: HP-01-600
Payment & Shipping Terms:
Minimum Order Quantity: 1-5pcs
Price: $3.83-$11.29/sets
Packaging Details: colorful box
Delivery Time: 7days after final confirm
Supply Ability: 30000sets per month
Detailed Product Description
Power: 600W Application: Production Halls
Beam Angle: 120° Protection Grade: IP66
Ik Rating: IK08 LED Lifetime: 50000h
High Light:

600W Stadium High Bay Flood Light

,

Led Stadium High Bay Flood Light

,

IK08 Outdoor Tennis Court Light

About Die-casting Man Factory:

Buildings Stadium High Bay Flood Light 600W Outdoor Tennis Court Light 0

High Bay Floodlight Standard Manual Stadium Luminaire For Factory Buildings 600W outdoor Tenniscourt light



Code HP-01-200 HP-01-400 HP-01-600
Power 200W 400W 600W
PC lens degree 30°60°90°
Color Temperature 3000-6000K
Efficiency >120LM/W
Voltage AC90-305V 50/60Hz
Power Factor PF≥0.95
CRI(Ra) Ra≥70
Ambient Temperature -40-45
Ambient Humidity 20%-90%RH
Lifetime(hrs) 50000
IP Rate IP65
Net Weight 8kg 16kg 24kg
Gross Weight 9kg 18kg 27kg


Description:



300W Outdoor Led Floodlight with 3030 LED Chips high quality die-casting aluminum body,IP65,3Years warranty.



1. High light intensity , simple designs and ideally suited.


2. High quality Die casting aluminum boday with anti-corrosiontreatment and with electrostatic plastic coating.



3. LED Floodlight housing can make 200W.



4. Highly polished aluminum reflector.



5. Adjustable single bracket could make the light for 120 degree around.



6. High Efficient and power factor led power supply .



7. Obtain a 50-70% energy saving compared with halogen lamps.



8. Replace traditional SON and Metal Halide which consume 400W.





Applications:



LED high bay luminaire for factory buildings, production halls, assembly halls, storage buildings, sales areas, exhibtion spaces, ...



Specifications



Model Number

HP-01-600

Electrical Specifications

LED QTY

1008pcs

TotaLPower consumption

600W

Operation Voltage

85-265VAC

Operating Humidity

10%~90%

Working Temperature

-30 ~ 50°C

Power Fact(PF)

>0.9

Driver Efficiency

> 0.9

Photometric Specifications

LED Luminous Flux

20000 lm - Initial



20000 lm - Maintain

Led Luminous Efficiency

>70LM/W

CRI

Ra ≥ 70

LED Color

3000k-6500k

Beam Angle

120 degree

Mechanical Specifications

IP Rating

IP65

Warranty

3Years

Heat Radiator

die-casting body as heat sink

Lens

Patented anti-glare optic lense

Fixture Dimension

115.06*141.9*51.14MM

Fixture Weight

32KGS



Packing Information

Packing Type

1pcs /ctn

Packing Dimension

69*56*44CM

Packing Weight

37KGS





Buildings Stadium High Bay Flood Light 600W Outdoor Tennis Court Light 1

Buildings Stadium High Bay Flood Light 600W Outdoor Tennis Court Light 2
