Multifunctional Led Stadium Flood Light For Sporting Grounds Led Flood Lamp 50w

Multifunctional Led Stadium Flood Light For Sporting Grounds Led Flood Lamp 50w
Multifunctional Led Stadium Flood Light For Sporting Grounds Led Flood Lamp 50w
video play

Large Image :  Multifunctional Led Stadium Flood Light For Sporting Grounds Led Flood Lamp 50w

Product Details:
Place of Origin: Ningbo China
Brand Name: Die Casting Man
Certification: CE, RoHs, ENEC, CB
Model Number: SLFR03-15
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiation
Packaging Details: Carton box with styrofoam package
Delivery Time: 7-40 days base on order quantity
Payment Terms: T/T, Western Union, L/C
Supply Ability: 10000pcs/month
Detailed Product Description
Model: SLFR03-15 Wattage: 50W
LED Lifetime: 50000h / Luxon 5050 CCT: 3000K, 4000K, 5700K, 6500K
Luminous Flux: 19500-22500lm Warranty: 5 Years
Material: Die Casting Aluminum PF: ≥0.95
IP: 66 IK: 08
High Light:

Ik08 Led Outdoor Stadium Lighting

,

Multifunctional Led Stadium Lights

,

Sporting Grounds Led Flood Lamp 50w

Multifunctional Led Stadium Flood Light Dual Purpose  For Sporting Grounds module led flood lamp 50w

Multifunctional Led Stadium Flood Light For Sporting Grounds Led Flood Lamp 50w 0Multifunctional Led Stadium Flood Light For Sporting Grounds Led Flood Lamp 50w 1

Product Specification
LED Power Consumption: 100W-600W
Operating Voltage: AC85-305V 50/60HZ
Power Factor: >0.95;
LED Luminous Efficiency: 130LM/W
Lamp Efficiency: >0.9;
Material: Die-casting aluminum body;
IP Rating: IP65;
Warranty: 3-5 years;
Finishes: White/Black/Gray;



Input voltage AC 100V-240V
Freqency range 50HZ-60HZ
Power factor >0.95
Chip brand EPISTAR/bridgelux/
Power brand /MeanWell/inventronics
LED quantity (3030 PLAN) 30W (SLFR03-13) 48PCS 8S6P(16H1)
40W (SLFR03-13) 48PCS 8S6P(16H1)
50W (SLFR03-13) 48PCS 8S6P(16H1)
50W (SLFR03-15) 64PCS 8S8P(16H1)
60W (SLFR03-15) 96PCS 8S12P(6H1)
100W (SLFR03-110) 144PCS 8S18P(16H1)
150W (SLFR03-110) 216PCS 8S27P(6H1)
200W (SLFR03-120) 256PCS 8S32P(16H1)
240W (SLFR03-120) 320PCS 8S40P(6H1)
300W (SLFR03-140) 432PCS 8S54P(16H1)
400W (SLFR03-140) 576PCS 8S72P(16H1)
460W (SLFR03-140) 720PCS 8S90P(6H1)

LED quantity (5050 PLAN) 30W (SLFR03-13) 12pcs 2S6P(6H1)
40W (SLFR03-13) 12pcs 2S6P(6H1)
50W (SLFR03-13) 12pcs 2S6P(6H1)
50W (SLFR03-15) 24pcs 2S12P(6H1)
60W (SLFR03-15) 24pcs 2S12P(6H1)
100W (SLFR03-110) 54pcs 2S27P(6H1)
150W (SLFR03-110) 54pcs 2S27P(6H1)
200W (SLFR03-120) 96pcs 2S48P(6H1)
240W (SLFR03-120) 96pcs 2S48P(6H1)
300W (SLFR03-140) 144pcs 2S72P(4H1)
400W (SLFR03-140) 216pcs 2S108P(6H1)
460W (SLFR03-140) 216pcs 2S108P(6H1)
16in1 lens Angle type:20*60°/20°/T1/T2/T3/T4/T5/30°/60°/90°/P50
6in1 lens Angle type:30°(5050)/60°/90°/ T2/T3
DRIVER Match with FR03-13 XLG-25/XLG-50 EUC- 35/EUC-060
DRIVER Match with FR03-15 SS-50U/SS-50H/SS-60H/XLG-50/XLG-75/EUC-60
DRIVER Match with FR03-110 SS-100VA/SS-150VA/
EUM-100/EUM-150/XLG-100/XLG-150
DRIVER Match with FR03-120 XLG-200/XLG-240/SS-200VA/EUM-200
DRIVER Match with FR03-140 2PCS XLG-150/2PCS XLG-200/2PCS XLG-240
2 PCS SS-200VA / 2PCS SS-240VA
2PCS EUM-200 /2PCS EUM-240
System light effect 120-130 lm/W
Power efficiency >90%
Color temperature 2700-6500K
Color rendering index Ra≥70
Light distribution Bats airfoil light distribution
Light design Lens light distribution
LED Junction temperature ≤ 90℃
Working temperature -30℃ — +50℃
Storage temperature -30℃ — +50℃
IP Grade IP66
Working life-span >50,000H
Power connection line Brown L
Blue N
Yellow/Green G
Color of lamp shell Black / Silver/Grey
Beam angle 30/60/90/120/type II/type III/P50
Support tube diameter
Lamp weight : N.W. (SLFR03-13) 1.71kg
(SLFR03-15) 2.5kg
(SLFR03-110) 4.85kg
(SLFR03-120) 6.65kg
(SLFR03-140) 13.4kg
  L(MM) W(MM) H(MM)
Product size(SLFR03-13) 230 270 50
Product size(SLFR03-15) 320 224 50
Product size(SLFR03-110) 442 291 62
Product size(SLFR03-120) 520 342 65
Product size(SLFR03-140) 620 450 84

SLFR03-13 master carton size (10pcs/ctn) 487 300 295
SLFR03-15 master carton size(6pcs/ctn) 610 375 255
SLFR03-110 master carton size (4pcs/ctn) 475 415 340
SLFR03-120 master carton size (2pcs/ctn) 565 395 233
SLFR03-140 master carton size (1pcs/ctn) 660 Multifunctional Led Stadium Flood Light For Sporting Grounds Led Flood Lamp 50w 2480 125





Multifunctional Led Stadium Flood Light For Sporting Grounds Led Flood Lamp 50w 3

Multifunctional Led Stadium Flood Light For Sporting Grounds Led Flood Lamp 50w 4

Multifunctional Led Stadium Flood Light For Sporting Grounds Led Flood Lamp 50w 5

Certification

Multifunctional Led Stadium Flood Light For Sporting Grounds Led Flood Lamp 50w 6



Test Machine

Multifunctional Led Stadium Flood Light For Sporting Grounds Led Flood Lamp 50w 7

Is there anything else you want to know about this lamp?

Questions
1.Q:What’s the warranty for your products
A: Normal produts in 5 years.Also can according your requirment
2.Q:What’s the delivery time
A:5days for samples,25days for housing,30days for finished lamp
3.Q:Can I put my logo on the products.
A:Of couse you can.Print the logo or make a mold engrave the logo on the products both ok for us.But engrave the logo should according the MOQ,usually need more than 1000pcs.
4.Q:Which port did you in.
A:We are in Ningbo port.And Shanghai port is ok for us.But other port is too far for us.We are no very suggest you choose other port,it will increase the cost.
5.Q:Which brand’s drvier did you use?
A:For our standard products,we will use with inventronic.But you also can choose .meanwell and osram.It’s depen on your like.If you want to the lower cost,their also have some Chinese brand for your choose,such as Moso ,sosen
6.Q:How about the chips.Which one did you use?
A:In normal we will use with philip 3030,you can choose the CCT RA by yourself.Ofcouse 5050 is also ok for us.We can design it according your requirement.
7.Q:How about the lens,is there any photometric for choose.
A:Yes we have many photometrics for each items for your choose,you can see it during our catalogue.The size which we use for the lens is 50*50mm,I think many customer will lke this one.And we also can use the ledil lens,but it will be take a little longer time for the delivery time.
8.Q:If I want to use with neam socket,is ok for this products?
A:Yes of couse.You see,there have a base ,we leave this to make nama hole for all the items for this family.And it also can make zhaga hole.You can choose it by yourself.
9.Q:What’s the protection grade for your products
A:IP66 IK08
10.Q:What’s grade for your powder coating
A:Normal is C2 grade,but If the customer has special request,such as used at the seaside,in this case,we can use phosphating with Akzo powder to reach higher levels,like C3,C4.We can make the different levels according your requirment.
11.Q:About the powder coating,which colour did you always use?Can I choose the colour which I like?
A:Usually we will provide black and gray two colour for your choose.But customize also ok for us.Just provide the RAL No. Or your colour plate,we can according this to make it.
12.Q:Is there any extra cost in this way.
A:If the MOQ reach to 500pcs,it will be free.
13.Q:How about the package for your products
A:Each 1pcs with a PE bag, packing with a foam then put into the carton.It must be very safty to protect the products.And if you need the pallet ,we also can help to add it.
14.Q:Do you accept OEM?
A:Yes of couse.Our company have our own diecasting machine,mold design team.We also have many OEM customers.Just take care for it.We can help to design the products which you need.
