Product Details:
Payment & Shipping Terms:
|
| Manufacturer: | Die-casting Man | Wattage: | 50W |
|---|---|---|---|
| Application: | ROAD | Fixture Color: | Black, White, Gray |
| Material: | Die Casting Aluminum | IP Rating: | IP66 |
| Highlight: | light housing,led tunnel lighting |
||
SPECIFICATION:
| Item NO. | ZHSL-10-50 | ZHSL-10-100 | ZHSL-10-150 |
| LED Quantity | 50W* 1PC | 50W* 2PC | 50W* 3PC |
| Rated Power | 50W | 100W | 150W |
| Color Temperature | 2700-6500K optional | 2700-6500K optional | 2700-6500K optional |
| Initial Luminous Flux | 4000lm | 8000lm | 12000lm |
| Frequency Range | 50-60Hz | 50-60Hz | 50-60Hz |
| Power Factor | PF>0.95 | PF>0.95 | PF>0.95 |
| Color Rendering Index | Ra>70 | Ra>70 | Ra>70 |
| Temperature Working Condition | -40℃ - 50℃ | -40℃ - 50℃ | -40℃ - 50℃ |
| Humidity of Working Condition | 20-90% | 20-90% | 20-90% |
| LED Lifetime | 50000h | 50000h | 50000h |
| Protection Grade | IP65 | IP65 | IP65 |
| Installation Pipe Diameter | 60mm | 60mm | 60mm |
| Installation Height | 6-8m | 6-8m | 6-8m |
| Net Weight | 3 kgs | 4.8 kgs | 7.2 kgs |
| Gross Weight | 3.4 kgs | 5.2 kgs | 8 kgs |
| Product Size | 480*174*93mm | 600*235*99mm |
Product Dimension:
Material and features:
1. Light fitting totally made of die-casting aluminum.
2. COB light source seamless joint on the die-casting shell,
with good heat dissipation and long lifetime.
3. Wide choice of lamp including 30W, 40W, 50W, 60W, 100W and 150W LED.
4. IP65 Rated for external use.
Application:
1. Warehouse Lighting, Factory Lighting, Industrial Lighting
2. Garage Lighting, Workshop Lighting
3. Outdoor Area Lighting, High Mast Lighting
4. Supermarket Lighting, Store Lighting
5. Tunnel Lighting, Bridge Lighting
6. Gas Station Lighting
Payment:
30% deposit and 70% rest payment upon the copy of BL
Light Distribution Curve:
