| Model: | YASL-33-150 | Input Wattage: | 120w150w 180w |
|---|---|---|---|
| Installation Pipe Diameter: | φ48/60mm | Installation Height: | 3-8 |
| Input Voltage: | 90~305Vac | Frequency Range: | 50/60Hz |
| Materials: | ADC12 Die-cast Aluminum | External Screws: | 304 Stainless Screws |
| Highlight: | Outdoor City Lighting led street lights,adjustable bracket led street lights,150w led street lights |
||
Compliance with international standards ENEC, CB, CE, EMC, LM79, Rohs …
Full wattage from 30 to 320W, with ultra-high luminous efficiency and various lighting distribution
Intelligent control system: timing dimming, 0-10v dimming, Dali, Zigbee, NB-Lot, etc
Features
Simple and fashionable crescent appearance design
Simple and stylish exterior design
Modular lens
Adjustable bracket both available for horizontal and vertical installing
| Model | YASL-33-50 | YASL-33-100 | YASL-33-150 | YASL-33-200 | YASL-33-240 | ||||||
| Input Wattage (W) | 30/40/50 | 60/80/100 | 120/150/180 | 180/200/240 | 240/320 | ||||||
| Installation Pipe Diameter | φ48/60mm | φ48/60mm | φ60mm | φ60mm | φ60mm | ||||||
| Installation Height (m) | 3-8 | 6-10 | 8-12 | 8-12 | 10-14 | ||||||
| Input Voltage | 90~305Vac | ||||||||||
| Frequency Range | 50/60Hz | ||||||||||
| Power Factor | ≥0.9 | ||||||||||
| Light source | LED | ||||||||||
| Driver | Inventronics | ||||||||||
| Meanwell (optional) | |||||||||||
| other brand of driver(upon request) | |||||||||||
| Luminaire efficacy (lm/W) | 130-190 | ||||||||||
| Color Temperature | 4000K (3000K/5000K,5700K upon request) | ||||||||||
| Color rendering index | ≥70 | ||||||||||
| Diming | Dali (optional) | ||||||||||
| 1-10V (optional) | |||||||||||
| PWM (optional) | |||||||||||
| Smart control management system (upon request) | |||||||||||
| The environment temperature | -40～45℃ | ||||||||||
| Humidity of Working Condition | 20%～90%RH | ||||||||||
| Protectin Grade | IP66 | ||||||||||
| Protection level | IK08 | ||||||||||
| Standards & Certifications | ENEC | ||||||||||
| CB | |||||||||||
| CE | |||||||||||
| Rohs | |||||||||||
| Options | Photocell | ||||||||||
| Surge protection | |||||||||||
| External cable (length upon request) | |||||||||||
| Smart control device | |||||||||||
| Materials | Housing: ADC12 die-cast aluminum | ||||||||||
| Cover: Toughened Glass | |||||||||||
| External Screws: 304 stainless screws | |||||||||||
| Color | Grey/Black ( other upon request) | ||||||||||
SL-33-xxx Explosion diagram
SL-33 Photometric data
Product structure
| Bracket installation direction 180° | Bracket installation direction 90° | ||||||||
|
|
Note: when the product leaves the factory, the bracket installation direction is at 180°. When the lamp installed on the lamp pole, adjust the bracket direction according to the situation (just remove the two screws that fixing in the handle, Adjust the bracket to the appropriate position and then fix it, without other accessories)
Bracket installation direction
| Installation Angle ±15° adjustable | Installation Angle ±15° adjustable | ||||||||
|
|
Product size and weight
| Outline dimension drawing | Adjustable Angle diagram | ||||||||
|
|
| Model | Product size (mm) | Packing size (mm) | G.W | N.W | |||||
| L | W | H | L | W | H | (kgs) | (kgs) | ||
| YASL-33-50 | 400 | 159 | 101 | 420 | 180 | 160 | / | / | |
| YASL-33-100 | 493 | 175 | 91 | 515 | 195 | 150 | / | / | |
| YASL-33-150 | 575 | 221 | 91 | 595 | 240 | 150 | / | / | |
| YASL-33-200 | 670 | 241 | 91 | 690 | 260 | 150 | / | / | |
| YASL-33-240 | 772 | 278 | 91 | 790 | 290 | 150 | / | / | |
