IP66 Aluminum LED Street Light 300W 3000K-6000K Color Temp 120° Beam 4000LM 50

IP66 Aluminum LED Street Light 300W 3000K-6000K Color Temp 120° Beam 4000LM 50
IP66 Aluminum LED Street Light 300W 3000K-6000K Color Temp 120° Beam 4000LM 50 IP66 Aluminum LED Street Light 300W 3000K-6000K Color Temp 120° Beam 4000LM 50

Large Image :  IP66 Aluminum LED Street Light 300W 3000K-6000K Color Temp 120° Beam 4000LM 50

Product Details:
Place of Origin: Ningbo, China
Brand Name: Die-casting Man
Certification: CE. EMC, LVD, ENEC, RoHs
Model Number: YASL-35-100
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: US$21.6 - US$44.6
Packaging Details: 1PC/CTN
Delivery Time: 7-35DAYS
Payment Terms: TT
Supply Ability: 50000PCS/M
Detailed Product Description
Beam Angle: 120° IP Rating: IP66
Voltage: AC85-265V Power: 30W - 150W - 300W
Color Temperature: 3000K-6000K Working Temperature: -20℃-50℃
Luminous Flux: 4000LM Lifespan: 50,000 Hours
High Light:

120° Aluminum LED Street Light

,

3000K-6000K Aluminum LED Street Light

,

300W 4000LM Aluminum LED Street Light

Product Description:

This street light has a high CRI (Color Rendering Index) of >80, which means it can produce bright and vivid colors that are close to the natural light. It is available in three different power options: 30W, 150W, and 300W, allowing you to choose the right amount of illumination for your specific needs.

The Aluminum Led Street Light has a wide voltage range of AC85-265V, which makes it suitable for different electrical systems. It has a beam angle of 120°, which provides a wide coverage area and ensures that every corner is well-lit.

This street light comes with a 3-year warranty, which gives you peace of mind knowing that you are protected against any manufacturing defects. It is also energy-efficient, which means it can help you reduce your electricity bills while providing superior lighting performance.

Whether you are looking to improve the lighting of your street, parking lot, or walkway, this Aluminum Led Street Light is an excellent choice. It is easy to install, requires minimal maintenance, and delivers reliable lighting performance for years to come.



Product Code YASL-25-40(M) YASL-25-60(M) YASL-25-100(M) YASL-25-150(M) YASL-25-240(M)
Input Wattage(W) 30-50 50-80 60-120 120-200 200-320
Number of lenses(PCS) 4 6 9 15 24
Product Size(m m) 563x215x110 613x240x110.2 654x256x114 780x287x114 834x341x114
Packing Size(m m) 610x250x260 660x280x260 710x300x260 810x330x260 860x380x260
Net Weight (kgs) 2.2 2.6 3.1 4 5.5
Gross Weight (kgs) 4.9 5.7 6.7 8.5 11.5
Quantity of packing (pcs) 2 2 2 2 2
Installation Height (m) 3~8 4~8 6~10 8~12 8~14
Installation Pipe Diameter 60 60 60 60 60/76
adjustable angle ±15°Adjustable
Materials Housing:ADC12;Cover:Toughened Glass;Screws:304stainless screws
Spray colors Double Grey; Sandy Black; Matt Silver
Led brand LUMILEDS, OSRAM,CREE(Optional)
Led Specifications 3030,5050(Optional)
Optical effect 130~190 lm/w(Optional)
Color Temperature 2700K,3000K,3500K,4000K,5000K,5700K,6500K(Optional)(Reference: Energy Star)
color rendering index Ra≥70;Ra≥80;Ra≥90(Optional)
Optics TYPEI,TYPEII,TYPEIII,TYPEV,TYPEIV(Optional)
Input Voltage AC90~305V
Security level ClassI/ClassII/Class1/Class2(Optional)
Frequency Range 50/60Hz
Power Factor PF≥0.95
Protection Overcurrent/Short circuit/Over temperature
Dimming mode Time control/0-10V/ Optical control/Microwaves/DALI(Optional)
Lightning protection 10KV/15KV/20KV(Optional)
Working conditions Range -40 to 45℃,20% to 90%RH
Warranty 5/8 year(Optional)
Protection level IP66;GlassIK08/09/10(Optional),Lamp shell IK08.
Certifications ENEC;CE;CB;IEC;RoHS;TUV;Lightning protection;LM-79;LM-80;IP66


Applications:

The Die Casting Man Aluminum Streetlamp Housing is suitable for mounting heights of 6m, 8m, 10m, and 12m, making it a great option for street lighting applications. Its 120° beam angle provides ample coverage for large areas, and the 3000K-6000K color temperature ensures that the light is bright and clear.

In addition to its standard features, the YASL-35 also has a custom design zhaga sensor for street lighting 100W which is perfect for areas where motion detection is required. The product has a minimum order quantity of 1PC and a price range of US$21.6 - US$44.6, making it affordable and accessible to a wide range of buyers.

The packaging details for the product include 1PC/CTN, and the delivery time ranges from 7-35 days. Payment terms are TT, and the supply ability is 50000PCS/M. The product comes with a 3-year warranty, providing buyers with peace of mind.

Overall, the YASL-35 Aluminum Led Street Light is an excellent choice for anyone looking for a high-quality and reliable product for their outdoor lighting needs.



Customization:

Product Customization Services for Aluminum LED Street Light

Brand Name: Die-casting Man

Model Number: YASL-35

Place of Origin: Ningbo, China

Certification: CE, EMC, LVD, ENEC, RoHs

Minimum Order Quantity: 1PC

Price: US$21.6 - US$44.6

Packaging Details: 1PC/CTN

Delivery Time: 7-35DAYS

Payment Terms: TT

Supply Ability: 50000PCS/M

Working Temperature: -20℃-50℃

Power: 30W - 150W - 300W

Light Type: Street Light

Light Source: LED

Warranty: 3 Years

Product Attributes: Die Casting Man Aluminum Streetlamp Housing 6m 8m 10m 12m, Die Casting Man Aluminum Streetlamp Housing, Hot Sale Energy Saving Street Light



Support and Services:

The Aluminum Led Street Light product comes with a comprehensive technical support and services package to ensure optimal performance and longevity. Our team of experts is available to assist with installation, maintenance, and repair of the product. In addition, we offer training and educational resources to ensure that our customers are fully informed on the product's features and capabilities. Our technical support and services also include warranty coverage and replacement parts, as needed. We are committed to providing exceptional customer service and support for the Aluminum Led Street Light product.
