Product Description:
Tool-free detachable construction
Using LED 30305050 light source
Dimming options include: Time control, 0-10V, Optical control, Microwaves, and DALI dimming
Lightning protection levels available: 10KV, 15KV, and 20KV
Protection level rated at IP66 and IK08/09/10
Warranty options of either 5 years or 8 years
Features:
- Product Name: Aluminum Led Street Light
- Luminous Flux: 4000LM
- IP Rating: IP66
- Light Source: LED
- Color: Customized Ral. No. Such As Gray, Black, White
- Power: 30W - 150W - 300W
Technical Parameters:
Item NO.
| YASL-29-40 |
YASL-29-60 |
YASL-29-100 |
YASL-29-160 |
YASL-29-240 |
Wattage
| 30～60W |
50～90W |
80～140W |
130～200W |
200～300W |
Lens
| 4(MAX 6) |
6(MAX 8) |
9(MAX 12) |
16(MAX 20) |
24(MAX 30) |
Installation Height
| 3-6m |
4-8m |
6-10m |
8-14m |
12-14m |
Product Size(mm)
| 576X209X89 |
593X263X89 |
646X263X89 |
709X315X89 |
812X315X89 |
Packing Size(mm)
| 585X250X140 |
620X305X140 |
665X305X140 |
730X360X140 |
840X360X140 |
Net Weight
| 3.8kgs |
4.1kgs |
4.6kgs |
7.4kg |
9.5kg |
Gross Weight
| 4.2kgs |
4.5kgs |
5.0kgs |
7.9kg |
10.5kg |
Installation Pipe Diameter
Materials
| Housing: ADC12; Cover: Toughened Glass; Screws: 304stainless screws |
Body Color
| Gray, Black, customized Ral no. |
Applications:
Die-casting Man's Aluminum LED Street Light, model YASL-29-100M, is a versatile lighting solution suitable for various application occasions and scenarios. Crafted with ADC12 Aluminum Housing, this street light is not only durable but also dustproof, ensuring long-term performance in outdoor environments.
The IP66 waterproof rating of the ADC12 Aluminum Housing makes this street light ideal for use in areas prone to moisture and harsh weather conditions. Whether illuminating urban streets, highways, parks, or residential areas, this product delivers reliable lighting with a luminous flux of 4000LM and a customizable color temperature ranging from 3000K to 6000K.
Originating from Ningbo, China, this street light boasts certifications including CE, EMC, LVD, ENEC, and RoHs, guaranteeing compliance with international quality and safety standards. With a minimum order quantity of 1PC and a competitive price range of US$21.6 to US$23, the YASL-29-100M offers cost-effective lighting solutions for various projects.
Packaged securely with 1PC per carton, the delivery time ranges from 7 to 35 days, ensuring timely fulfillment of orders. Payment terms are convenient with TT, and the supply ability of 50000PCS per month makes this product readily available for large-scale projects.
Thanks to its customizable Ral color options such as gray, black, and white, this Aluminum LED Street Light can seamlessly integrate with different architectural styles and urban landscapes. The IP66 rating and dustproof properties of the ADC12 Aluminum Housing make it a reliable lighting solution for outdoor environments requiring robust performance.
Customization:
Customize your Aluminum LED Street Light with our Product Customization Services:
- Brand Name: Die-casting Man
- Model Number: YASL-29-100M
- Place of Origin: Ningbo, China
- Certification: CE, EMC, LVD, ENEC, RoHs
- Minimum Order Quantity: 1PC
- Price: US$21.6 - US$23
- Packaging Details: 1PC/CTN
- Delivery Time: 7-35DAYS
- Payment Terms: TT
- Supply Ability: 50000PCS/M
- Voltage: AC85-265V
- IP Rating: IP66
- Beam Angle: 120°
- CRI: >80
- Warranty: 5 Years
Enhance your lighting solution with ADC12 Aluminum Housing for a dustproof design and the Die Casting Man Aluminum Streetlamp Housing.
Packing and Shipping:
Product Packaging:
The Aluminum LED Street Light is carefully packaged to ensure safe delivery. It is wrapped in protective materials and placed in a sturdy cardboard box to prevent any damage during transit.
Shipping:
We offer fast and reliable shipping services for the Aluminum LED Street Light. Your order will be processed promptly and shipped out within 1-2 business days. You will receive a tracking number to monitor the status of your delivery.
