Product Specifications
| Item No. |
YASL-27-60M |
YASL-27-60M |
YASL-27-60M |
| Power |
40W |
50W |
60W |
| Lumen Efficiency |
160lm/w |
160lm/w |
160lm/w |
| Lumen |
6400lm |
8000lm |
9600lm |
| Product Size (mm) |
617x250x114 |
617x250x114 |
617x250x114 |
Working Voltage
AC100-265V 丨 50/60Hz
LED
Lumileds / Epistar / SANAN
CCT
3000K, 4000K, 5000K, 6000K
CRI
Ra>70 (standard)/ Ra>80
Driver
local
THD
<15%
Power Factor (PF)
PF>0.9
IP Rating
IP66
IK Rating
1K09
Holder
50mm/B60mm (standard)
Body Material
High pressure die-cast aluminum
Housing Color
Dark Grey/Black/Light Grey (available on request)
Cover Material
UV-resistant Polycarbonate
Working Environment
-20℃ ~+50℃, 10%~90%RH
Lifespan L70 at 25℃
> 50,000hrs
Mounting Type
Side entry or Vertical pole mounted ±15°
Dimmable
1-10V Dimming / Timer Dimming
Protection Class
Class I (standard) / Class Ⅱ
Standards
CE, RoHS, ENEC, CB, LM79, LM80, TM-21, IP66, IK09
Available on request
NEMA socket (3/5/7pins), ZHAGA socket, Short cap, Photocell, Motion sensor, NTC, OLC, DALI Dimming
Reasonable tolerance
Watt: ±10%, CCT: ±500K, Lumen efficiency: ±5%
Frequently Asked Questions
Q: What's the warranty for your products?
A: Normal products have 5 years warranty. We can also customize according to your requirements.
Q: What's the delivery time?
A: 5 days for samples, 25 days for housing, 30 days for finished lamps.
Q: Can I put my logo on the products?
A: Yes, you can. We can print the logo or make a mold to engrave the logo on the products. Engraving the logo requires a minimum order quantity, usually more than 1000 pieces.
Q: Which port do you ship from?
A: We ship from Ningbo port. Shanghai port is also available. Other ports are not recommended as they will increase costs.
Q: Which brand's driver do you use?
A: For standard products, we use Inventronic. You can also choose Philips, Meanwell, or Osram. We also offer Chinese brands like Moso and Sosen for lower cost options.
Q: How about the chips? Which ones do you use?
A: Normally we use Philips 3030, and you can choose the CCT and RA. 5050 chips are also available and we can design according to your requirements.
Q: How about the lens? Is there any photometric option to choose?
A: Yes, we have many photometric options for each item. We typically use 50x50mm lenses, and Ledil lenses are also available with slightly longer delivery time.
Q: If I want to use NEMA socket, is it ok for this product?
A: Yes, of course. The base is designed to accommodate NEMA holes for all items in this family. ZHAGA holes are also available.
Q: What's the protection grade for your products?
A: IP66 IK08
Q: What's the grade for your powder coating?
A: Normal is C2 grade. For special requirements like seaside use, we can use phosphating with Akzo powder to reach higher levels like C3, C4 according to your requirements.
