Tennis Court 400 Watt Pf0.95 Led Outdoor Sports Lighting

Tennis Court 400 Watt Pf0.95 Led Outdoor Sports Lighting
Tennis Court 400 Watt Pf0.95 Led Outdoor Sports Lighting Tennis Court 400 Watt Pf0.95 Led Outdoor Sports Lighting Tennis Court 400 Watt Pf0.95 Led Outdoor Sports Lighting

Large Image :  Tennis Court 400 Watt Pf0.95 Led Outdoor Sports Lighting

Product Details:
Place of Origin: China
Brand Name: Die Casting Man
Certification: CE
Model Number: HP-01-400
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: Negotiation
Packaging Details: Carton box
Delivery Time: 10-35 days base on order quantity
Payment Terms: By T/T 30% in advance and 70% after shipment EXW/FOB NINGBO, Western Union, L/C
Supply Ability: 10000PCS/Month.
Detailed Product Description
Material: ADC12 Aluminum CRI: >70
Fixture Color: Grey Input Voltage: AC85 - 265V
Working Ambient Temperature: -30℃ - 50℃ IP: 65
Lamp Power: 400w
High Light:

400 watt led stadium lights


400w led outdoor sports lighting


pf0.95 led outdoor sports lighting

LED Outdoor Flood light housing diecasting aluminium ADC-3 with driver box and bracket


Product Description:


Product Code ZHHP-01-400
Input Wattage 400W
Color Temperature 3000-6500K
Luminous Flux 46000-50000lm
Input Voltage AC90-305V
Frequency Range 50/60Hz
Power Factor PF≥0.95
color rendering index Ra≥70
Temperature of Working Condition -40--50
Humidity of Working Condition 20%-90%RH
LED Lifetime 50000h
Protectin Grade IP66
Installation Height 15-20m
Net Weight 24.0kg
Gross Weight 24.8kg
Packing Size 620X660X240mm

LED Engine Module
                             LED life time of 30,000+ hours

·                     High power integrated packaging LED chips, 120° beam spread available

·                     Minimum CRI of 70, custom CRI available

·                     Operating temp: -30º C to +60º C

·                     No toxic chemicals / ROHS compliant

·                     Low Tj for long life, low lumen depreciation

·                     CE certified, meets ROHS standards

·                     Eligible for Rebates, Design Lights Consortium® Qualified*

·                     50-80% energy savings

·                     Manufactured in the China

·                     Standard distribution is Type V, others distributions available

·                     Standard AC input of 85-265v VAC, up to 480v available

·                     EMI filter: 47CFR, part 2, part 15

·                     Power factor: >0.9

·                     Total harmonic distortion: <20%

·                     Surge protection: IEC/EN 61000-4-5 EMC test standard

·                     Licensed electrician required for installation

·                     Rugged, fully sealed, die-cast aluminum housing

·                     UV-resistant, multi-layer, architectural color, powder coat finish

·                     High impact, heat resistant, tempered lens
Energy Control Options

·                     Motion detection available

·                     Photo sensors available
Technical Specifications

.Die casting aluminum body with anti-corrosion treatment.
.Highly polished aluminum reflector.
.Toughened glass with good light transmition rate.
.IP65 Rated for external use
.Equipped with LG/CREE LED chip, generate high luminous flux
.LED emiiter brand can be varied according to requirement.
.High efficient and power factor LED power supply.
.Longlife span over 50000 Hours.
.Obtain a 50-70% Energy Saving compared with Halogen Lamps.
Motorways , Major roads, minor roads, roundabouts, crossings and industrial areas.
Available housing colors: Black, Grey, White.

We are a professional Die casting factory for around 30years.

If you are importing lighting fixture,of sure our company will be a good option for you choice.
1)we can use the material according to your component request.
2)we are die-casting manufacturer for around 30year, we are professional on lighting design and  the quality and cost control.
3)we have profession engineer to make sure the design of the housing or the technical date of the product is meet your requirement.
   make your idea/drawing to be truth.
4)we are a lighting industrial park,so we can offer the best delivery for you.
5)we have good experience on assembling and  exporting lighting fixture for around 10 years,so can offer you very good service.
Note: Additional wattages and configurations available upon request. Specifications are subject to change without notice.
