Product Details:
Payment & Shipping Terms:
|
| Manufacturer: | Ninghai Zhouhua Die Casting Co.,Ltd | Material: | ADC12 Aluminum |
|---|---|---|---|
| Wattage: | 50W | Fixture Color: | Sandy Dark Grey |
| IP: | 65 | LED Color: | WW/NW/CW |
| CRI: | >70 | Input Voltage: | AC85 - 265V |
| Frequency Range: | 50 - 60Hz | Working Ambient Humidity: | 10% - 90% |
| Working Ambient Temperature: | -30℃ - 50℃ | ||
| High Light: | street light housing,led street light enclosure |
||
50w Led Street Lamps Outdoor Street Light Led Water Proof Eco Friendly
Quick Detail:
|
Name |
50w led street lighting |
Application |
Use for Street |
|
Color |
Grey,black,White,or custom color |
Feature |
New Design |
|
Lamp Luminous Flux(lm) |
5000LM |
Certificate |
TUV/UL /CE/ROHS |
Description:
New Patent 50W SMD LED streetlight made of High quality Die Casting Aluminum housing +LG High lumen chip+Meanwell Driver
1. The latest version of high power SMD LED Street Light Housing
2. State-of-art designing with completed die-casting body as heat sink offer the maximum heat management system,which can hold maximum 24pcs of 1-5W LG SMD led.
3. Patented anti-glare optic lense enable this street light give an maximum 120 degree light spread,with an asymmetrical polar curve.
4. IP65 protection grade.
5. User-friendly mechanical designing,easy to assemble the led,potic lense and led power supply.
6.The Led power supply is designed to installed with two U brackets,so any brand of led power supply can be easily installed.
Applications:
minor roads,Motorways,Major roads,roundabouts,crossing and industrial areas.
Specifications
|
Model Number |
ZHSL-09-50 |
|
|
Electrical Specifications |
LED QTY |
24PCS of LG chip |
|
TotaLPower consumption |
50W |
|
|
Operation Voltage |
85-265VAC or 12VDC or 24VDC |
|
|
Operating Humidity |
10%~90% |
|
|
Working Temperature |
-30 ~ 50°C |
|
|
Power Fact(PF) |
>0.95 |
|
|
Driver Efficiency |
> 0.9 |
|
|
Photometric Specifications |
LED Luminous Flux |
6500 lm - Initial |
|
|
5000 lm - Maintain |
|
|
Led Luminous Efficiency |
>100LM/W |
|
|
CRI |
Ra ≥ 70 |
|
|
LED Color |
3000k-6500k |
|
|
Mechanical Specifications |
IP Rating |
IP65 |
|
Warranty |
3Years |
|
|
Heat Radiator |
die-casting body as heat sink |
|
|
Lens |
tempering glass |
|
|
Fixture Dimension |
485x230x98MM |
|
|
Fixture Weight |
3.5kgs(7.8lbs) |
|
|
Packing Information |
Packing Type |
1unit /ctn |
|
Packing Dimension |
52 x25 x21 cm (20.5” x9.85” x8.3”) |
|
|
Packing Weight |
6.5kgs(14.4lbs) |
|
